THQB1120ST1 - GE 20 Amp 1 Pole Bolt-On Shunt Trip Circuit Breaker
In stock
Favorite Favorite

THQB1120ST1 – GE 20 Amp 1 Pole Bolt-On Shunt Trip Circuit Breaker

$92.99

SKU: THQB1120ST1 Categories: ,

Description

General Electric THQB single Pole bolt-on molded case circuit breaker with shunt trip Miniature circuit breaker has a voltage rating of 120 VAC 120/240 VAC and current rating of 20 Amps. It has an interrupting current rating of 10 kilo-Amps at 120 VAC and 10 kilo-Amps at 120/240 VAC.It accommodates copper wire of size 14 - 8 AWG and aluminum wire of size 12 - 8 AWG.

Specifications

  • Trip Style: Non-Interchangeable
  • Frame Type: Q-Line
  • Amperage: 20 A
  • System Voltage: 120 Vac, 120/240 Vac
  • Poles: 1
  • Trip Function: LI
  • Continuous Current Rated: Standard
  • 120 Vac Interrupting Rating: 10 KAIC
  • 120/240 Vac Interrupting Rating: 10 KAIC
  • Suitable for Reverse Feed: Yes
  • Long Time: Fixed
  • Instantaneous: Fixed
  • Protective Relays: No
  • Current Metering: No
  • Special Markings: HACR, SWD
  • GSA Compliance: Yes
  • Authentic General Electric Product

Free Shipping Policy
Parcel shipments with item value over $200.00 qualify for free economy shipping within the continental US. Please indicate at checkout if USPS or UPS is a required shipment method. We do not charge a handling fee or require a minimum amount on any order. Breakers & Controls Florida does not ship on customer accounts.

Same Day Shipping
We strive to ship out your items the same day the order is placed. In rare circumstances Breakers & Controls Florida may reserve up to 5 business days to consolidate orders for complete shipment.

Additional information

Weight 2 lbs
Condition

New
GTIN
