THQB2150ST1 – GE 50 Amp 2 Pole Bolt-On Shunt Trip Circuit Breake

$144.99

SKU: THQB2150ST1 Categories: ,

Description

General Electric THQB series double pole single phase 50 ampere bolt-on molded case circuit breaker shunt trip with maximum voltage rating of 240V trip type thermal magnetic non-Interchangeable common trip and standard interrupting rating of 10 kiloampere at 120V used on AL AQ ALC AQC spectra series panelboard.

Specifications

  • Trip Style: Non-Interchangeable
  • Frame Type: Q-Line
  • Amperage: 50 A
  • System Voltage: 120 Vac, 120/240 Vac
  • Poles: 2
  • Trip Function: LI
  • Continuous Current Rated: Standard
  • 120 Vac Interrupting Rating: 10 KAIC
  • 120/240 Vac Interrupting Rating: 10 KAIC
  • Suitable for Reverse Feed: Yes
  • Long Time: Fixed
  • Instantaneous: Fixed
  • Protective Relays: No
  • Current Metering: No
  • Special Markings: HACR
  • GSA Compliance: No
  • Authentic General Electric Product

Free Shipping Policy
Parcel shipments with item value over $200.00 qualify for free economy shipping within the continental US. Please indicate at checkout if USPS or UPS is a required shipment method. We do not charge a handling fee or require a minimum amount on any order. Breakers & Controls Florida does not ship on customer accounts.

Same Day Shipping
We strive to ship out your items the same day the order is placed. In rare circumstances Breakers & Controls Florida may reserve up to 5 business days to consolidate orders for complete shipment.

Additional information

Weight 2 lbs
Condition

New
