FavoriteEATON HFD3070 3 Pole Non-Interchangeable Trip Thermal Magnetic Circuit Breakers
$654.99
Description
MOLDED CASE THERMAL MAGNETIC TYPE 4.13 INCH WIDTH X 3.38 INCH DEPTH X 6 INCH HEIGHT SIZE 600 VOLT MAX. AC VOLTAGE RATING 250 VOLT MAX. DC VOLTAGE RATING UL 489 CSA C22.2 APPROVAL 600 VOLT AC AT 50/60 HERTZ 250 VOLT DC VOLTAGE RATING 100 KILOAMP AT 240 VOLT AC AT 50/60 HERTZ 65 KILOAMP AT 480 VOLT AC AT 50/60 HERTZ 25 KILOAMP AT 600 VOLT DC 22 KILOAMP AT 250 VOLT DC INTERRUPTING RATING 70 AMP AT 40 DEG C CURRENT RATING 3 POLE(S) STANDARD PRESSURE LOAD TERMINAL TYPE FD FRAME TYPE INCLUDES LOAD TERMINAL APPLICABLE STANDARD NEMA AB1 AS 2184 BS 4752 IEC 157-1 SABS 156 SEV 157-1 VDE 0660 C HFD MODEL
Specifications
| Type | Molded Case- Thermal Magnetic |
| Frame Type | FD |
| Voltage Rating | 600 Volt AC at 50/60 Hertz- 250 Volt DC |
| Maximum AC Voltage Rating | 600 Volt |
| Maximum DC Voltage Rating | 250 Volt |
| Current Rating | 70 Amp at 40 Deg C |
| Number of Poles | 3 |
| Interrupting Rating | 100 Kiloamp at 240 Volt AC at 50/60 Hertz- 65 Kiloamp at 480 Volt AC at 50/60 Hertz- 25 Kiloamp at 600 Volt DC- 22 Kiloamp at 250 Volt DC |
| Terminal Type | Standard Pressure Load |
| Size | 4.13 Inch Width x 3.38 Inch Depth x 6 Inch Height |
| Approval | UL 489- CSA C22.2 |
| Model | C- HFD |
| Additional Information | Includes Load Terminal- Applicable Standard NEMA AB1- AS 2184- BS 4752- IEC 157-1- SABS 156- SEV 157-1- VDE 0660 |
| Features/Benefits | All Eaton’s F-Frame Circuit Breakers are HACR Rated- All F-Frame Circuit Breakers are Suitable for Reverse Feed Use |
Additional information
| Weight | 4.3 lbs |
|---|---|
| Condition | New, Used |
| GTIN |
