Portfolio ERM6A15830 Medium LED Module Recessed Downlight, 1500 lm, 80 CRI, 3000 K, 6″

The Portfolio 6″ LED recessed new construction downlight or wall wash specially designed for LED technology. Two-stage reflector system produces smooth distribution with excellent light control and low aperture brightness. Suitable for commercial construction and exceeds high efficacy requirements (with designated trims) for Title 24-2008 and IECC-2009. Downlight reflectors are wet location listed. Lower Shielding Reflector: Self-flanged, spun.050″ thick aluminum lower reflector in combination with a lensed upper optical chamber provides superior lumen output with minimal source brightness. Available in all Portfolio Alzak finishes. Trim Retention: Lower reflector is retained with two torsion springs holding the flange tightly to the finished ceiling surface. Plaster Frame / Collar: New Construction Housing: Die cast aluminum 1-1/2″ deep collar accommodates ceiling materials up to 2″. Universal Mounting Bracket: Accepts 1/2″ EMT, C channel and bar hangers and adjusts 5″ vertically from above and below the ceiling. Junction Box: (4) 1/2″ and (2) 3/4″ trade size pry outs positioned to allow straight conduit runs. Listed for (8) #12 AWG (four in, four out) 90°C conductors and feed thru branch wiring. Thermal: Extruded aluminum heat sink conducts heat away from the LED module for optimal performance and long life. LED: LED system contains a plurality of high brightness white LED’s combined with a high reflectance upper reflector and convex transitional lens producing even distribution with no pixilation. Rated for 50,000 hours at 70% lumen maintenance. Auto resetting, thermally protected, LED’s are turned off when safe operating temperatures are exceeded. Color variation within 3-step MacAdam ellipses. Flexible disconnect allows for tool-less replacement of LED engine from below ceiling. Available in 80 or 90 CRI.LED Modules and LED Trims.
