Favorite$73.99
| Type | Miniature- Thermal and Fixed Magnetic Trip- Common Trip |
| Number of Poles | 3 |
| Voltage Rating | 240 VAC at 50/60 Hz |
| Current Rating | 60 Ampere at 40 Deg C |
| Interrupting Rating | 22 Kiloamp |
| Terminal Type | Load Lug |
| Wire Size | 8 to 2/0 AWG (Copper/Aluminum) |
| Mounting | Plug-In |
| Used On | Loadcenter |
| Size | 3 Inch W x 3 Inch D x 3-1/8 Inch H |
| Approval | UL 489- CSA C22.2 |
| Brand Name | SPEEDFAXâ„¢- INSTA-WIREâ„¢ |
| Model | QPH |
| Additional Information | Frame Type QPH |
| Features/Benefits | Plug-In or Bolt-On Branch Circuit Breakers for Siemens Single Phase Load Centers- Saving Money-Two Safety Devices Combined into One- LED Trip Indicator-a Siemens Exclusive- Both Lugs at the Same Angle for Easier Wiring |
MINIATURE THERMAL AND FIXED MAGNETIC TRIP COMMON TRIP TYPE 3 INCH W X 3 INCH D X 3-1/8 INCH H SIZE LOADCENTER USED ON 8 TO 2/0 AWG (COPPER/ALUMINUM) WIRE SIZE UL 489 CSA C22.2 APPROVAL 240 VAC AT 50/60 HZ VOLTAGE RATING PLUG-IN MOUNTING 22 KILOAMP INTERRUPTING RATING 60 AMPERE AT 40 DEG C CURRENT RATING 3 POLE(S) LOAD LUG TERMINAL TYPE SPEEDFAX INSTA-WIRE BRAND FRAME TYPE QPH QPH MODEL
| Weight | 2.5 lbs |
|---|---|
| Condition | New, Used |
| GTIN |
