FavoriteMGA36400 – Square D – Molded Case Circuit Breaker I-Line Plug-In – 400 Amp – 3 Pole – 600 Volt
$2,099.99 – $4,499.99
Description
The Square D MGA36400 is a 3 Pole solid state molded case circuit breaker with a current rating of 400 Amps and a voltage rating of 600V. It has an interrupting rating of 65kA at 240VAC, 35kA at 277/480VAC, 18kA at 347/600VAC. The MGA36400 has a I-Line style plug-in connection type and includes LI - long time and instantaneous functions.
Specifications
| Type | Thermal Magnetic- Basic Electronic ET 1.0 |
| Voltage Rating | 600 Volt AC 50/60 Hertz |
| Current Rating | 400 Amp |
| Number of Poles | 3 |
| Interrupting Rating | 18 Kiloamp at 600 Volt AC |
| Trip Setting | 800 to 4000 Amp |
| Application | Power Distribution |
| Used On | I-Line Panelboard And Switchboard |
| Approval | UL- CSA |
| Brand Name | PowerPact™ |
| Model | MG |
| Additional Information | RoHS/REACH Compliant- Overall Dimension 8.27 Inch Width x 8.05 Inch Depth x 12.86 Inch Height- Frame Type M- Terminal Type I-Line Connection Line Lug Load- Control Type Operating Handle- Terminal Wire Size 3/0 AWG to 500 KCMIL (Copper/Aluminum)- Continuous Current Rating 80 Percent- Phase Connection Type CBA- Operation Ambient Air Temperature Rating -13 to 158 Deg F- Applicable Standard NOM- IEC |
| Features/Benefits | Returnable- RoHS/REACH Compliant- Mercury-Free- PVC-Free- Green Premium Product- Made in USA |
Additional information
| Weight | 17 lbs |
|---|---|
| Condition | New, Used |
| GTIN |
