FavoriteEGH3090FFB – Cutler Hammer Bolt-On 600V 90A 3 pole circuit breaker 65kA@480V
$602.99
Description
The Eaton EGH3090FFB is a 3 Pole thermal magnetic molded case circuit breaker with a current rating of 90 Amps and a voltage rating of 600Y/347VAC. It has an interrupting rating of 65kAIC at 480VAC, 35kAIC at 600Y/347VAC, 100kAIC at 240VAC. The EGH3090FFB has a bolt-on connection type and includes LI - long time and instantaneous functions.
Specifications
| Brand | Eaton |
| Series | G |
| Amperage | 90 |
| Voltage | 600Y/347VAC |
| Poles | 3 |
| Phase | 3 |
| Approval | CE, CSA, IEC, UL, KEMA, KEUR |
| Interrupting Rating | 65kAIC at 480VAC, 35kAIC at 600Y/347VAC, 100kAIC at 240VAC |
| Connection Type | Bolt-On |
| Protection | Thermal Magnetic |
| Functions | LI – Long Time and Instantaneous |
| Terminal Connection | Load side lug |
| Temperature Rating | 40°C |
| Circuit Breaker Type | EG |
| Action | Blow Open |
| Mpn | EGH3090FFB |
Additional information
| Weight | 3 lbs |
|---|---|
| Condition | New |
| GTIN |
